Vision lites and decorative panels for wood, hollow-metal and commercial interior doors — cut to your kit opening, tempered, and edged so glazing beads seat clean.
Rectangular lites cut to your steel kit opening with seamed edges.
Large single lites for glazed interior and office doors.
Arches, ovals and custom profiles cut on the CNC from your file.
Privacy patterns for conference rooms, clinics and stairwells.
| Common sizes | Any size to 90" × 144" |
| Thickness | 5/32", 3/16", 1/4" (4–6 mm) typical |
| Glass types | Clear, low-iron, satin/acid-look, obscure patterns |
| Edgework | Seamed standard · ground where the lite is handled at install |
| Size tolerance | ± 1/32" on cut size; squareness within 1/16" |
| Standards | CPSC 16 CFR 1201, ANSI Z97.1, ASTM C1048 · permanent temper mark |
| Lead time | 5–10 business days |
Need a spec not listed? We quote off your drawing, not off a catalog.
DXF, DWG, PDF or a dimensioned sketch. We check hole placement and edge distances against tempering limits before we price it — so the quote you get is the part you can actually have.
Start a quote →Something not covered? Call the shop — you'll reach someone who has run the oven.
Yes. Give us the kit's daylight opening and glazing bead allowance and we'll cut to the net size you need.
We supply satin substrate for the etched appearance, tempered like any other lite.
None. We run single replacement lites through repeating door programs.
Dimensions, thickness, finish and quantity are enough for a first number. Drawings and photos welcome.
