Single-lite and dual-pane inserts for sectional and carriage-house doors — cut, edged, frit-printed and tempered in one building, then shipped to your assembly line on a schedule you set.
1/8"–1/4" (3–6 mm) clear, obscure or tinted, seamed or ground edge, sized to your retainer profile.
Dual pane with warm-edge spacer for insulated door series; coated or obscure inboard lite.
Black or white ceramic bands that hide sealant and retainers, fired in during tempering.
CNC-cut arches, eyebrows and custom radii for carriage-house and specialty panels.
| Common lite sizes | Any size to 90" × 144"; typical 12"×20" to 24"×36" |
| Thickness | 1/8", 5/32", 3/16", 1/4" (3–6 mm) single · 1/2"–1" IG build-up |
| Glass types | Clear, low-iron, bronze, grey, obscure (rain, glue chip, satin) |
| Edgework | Seamed standard · ground or flat polish on request |
| Size tolerance | ± 1/32" on cut size; squareness within 1/16" |
| Standards | CPSC 16 CFR 1201, ANSI Z97.1, ASTM C1048 · permanent temper mark |
| Packaging | Interleaved on returnable racks or crated for LTL |
| Lead time | 5–10 business days · scheduled releases on blanket POs |
Need a spec not listed? We quote off your drawing, not off a catalog.
DXF, DWG, PDF or a dimensioned sketch. We check hole placement and edge distances against tempering limits before we price it — so the quote you get is the part you can actually have.
Start a quote →Something not covered? Call the shop — you'll reach someone who has run the oven.
Yes — dual pane with a warm-edge spacer, and we can mix an obscure or coated inboard lite with a clear outboard lite. Overall thickness is built to your retainer opening.
That's ceramic frit screen printing, done on site and fired during tempering. It won't peel, fade or chalk like an applied film.
Glazing in and adjacent to doors is a hazardous location under the IRC, so safety glazing is required. Every lite carries a permanent temper mark and meets CPSC 16 CFR 1201 Cat. II.
Standard sizes in stock thicknesses usually ship within the week. Send the pattern number or a measured sketch and we'll confirm the same day.
Dimensions, thickness, finish and quantity are enough for a first number. Drawings and photos welcome.
